Electric

WE-150-2(S)

WE-150-2(S)

Occasion: Entrance/Factory
Coverage: 90m² /180m² (Ceiling-suspended)
  • 150-2 _1_.png
  • 150-2 _2_.png
  • 150-2 _3_.png
  • 150-2S _1_.png
  • 150-2S _2_.png
  • 150-2S _3_.png
DETAIL

  • Utilizes the principle of double-sided light transmission to maximize insect attraction.

  • Outer grid designed with an intelligent fixed protective cover to prevent finger contact with the electric grid.

  • Electric grid supports continuous discharge.

  • Easy-to-clean collection tray.

  • Installation should avoid direct sunlight; prioritize ventilation areas or mosquito breeding sites.

  • 30W insect trap lamp, for indoor use only.

  • Equipped with two 15W UVA tubes (Philips), effective in attracting insects, mosquitoes, and flies.

  • Internal electric grid outputs 4000VAC to instantly kill insects.

  • Coverage area: approx. 90 m² (can be wall-mounted or ceiling-suspended).


    Product Name WE-150-2 / WE-150-2S
    Material Steel / Stainless Steel #304 & #430
    Tube Watts 30W
    Tube Type FL15W T8 x 2pcs UVA Tube
    Wavelength UVA 350~400nm
    Power Consumption 45W
    Output Voltage AC 4000V
    Certification TUV
    Input Voltage/Frequency Customized
    Coverage Wall-Mounted: 90m²
    Ceiling-suspended: 180 m²
    Dimension L 47 x W 13 x H 33 cm
    Weight 7 Kg
